New software release for Plura IP 2110 monitors.

Plura IP 2110 Monitor

SFP-25G / SFP-25G-H / SFP-10G Series

“TRUE-IP 25GbE / 10GbE 2110 4K/UHD and 3G/FHD Series”

We’re proud to announce the release of the NEW Plura IP 2110 monitor SFP-25G, SFP-25G-H and SFP-10G series firmware, FPGA and Web UI 22.10, 22.02 & 3.0.0 respectively highlighting Media LAN Data and Measurements analysis.

SFP-25G & SFP-25G-H the Industry’s FIRST & ONLY TRUE-IP 25GbE broadcast & media monitor solution, supporting uncompressed UHD and FHD based on SMPTE ST 2110 & ST 2022-7 and supports up to 4096 x 2160 resolutions.

The new firmware will deliver fresh new enhancements and tools that make displaying stream data faster and more convenient than ever before. With major increases in data analysis and information for the Media LAN streams in multiple layers, more efficient and comprehensive display platform, intuitive messaging platform, enhanced Plura Web UI interface and various models / sizes to fit your applications.

This article promises to be packed with useful information!

The new SFP-25G, SFP-25G-H and SFP-10G Firmware 22.10 and FPGA 22.02 will highlight the below changes and additions:-

Incremental and differential data analysis
Plura IP 2110 Monitor Media Lan ML1
Media LAN State 1 On Display Information

The monitor function key can be programmed to provide

  • PTP status and analysis data such as
    • Lock Status
    • GrandMaster ID
    • PTP Version
    • PTP Source
    • Offset time
    • Time Stamp
    • Configuration Mode
    • Domain information
    • VLAN ID
  • Media LAN ML1 and Media LAN ML2 SFP Status and measurement levels
    • Link Status
    • TX Power measurement
    • RX Power measurement
    • Temperature measurement
  • ST-2022-7 Hitless switching status
  • SDP Main and Aux streams URL status
    • Video URL
    • Audio URL
    • Ancillary URL
  • Main stream primary and secondary signal analysis, RX Packets and status
      • Signal Format
      • ST 2110-20 Video status
      • ST 2110-30 Audio status
      • ST 2110-40 Ancillary status
    • Aux stream primary and secondary signal analysis, RX Packets and status
      • Signal Format
      • ST 2110-20 Video status
      • ST 2110-30 Audio status
      • ST 2110-40 Ancillary status
    Plura IP 2110 Monitor Media Lan ML2
    Media LAN State 2 On Display Information
    OSD informative custom messaging and alarms

    Extensive and variety of customs and defined messages would be available on the display with different appearance programming and scheduling. To identify few as below

    • IP license notifications
      • license will expire soon: “”Warning: IP 2110 license will expire in XX day(s)”
      • license is expired: “Warning: IP 2110 license has expired! (XX day(s) ago)”
    Plura IP 2110 Monitor IP License
    IP License Notifications
    • Incorrect speed SFP module been inserted
      • “Warning: Detected invalid speed SFP module inserted
    Plura IP 2110 Monitor SFP Warning
    Invalid SFP Warning
    • Identification
      • Monitor MAC address ID: [aa.bb.cc.dd.ee.ff]”
        Plura IP 2110 Monitor Mac address
        Mac Address On Display Message
        • Over temperature alarms for IPSOC and/or SFP modules
          • Over temp: “Warning: over temperature condition detected (XXX)”
          • Critical temp (shutdown): “Warning: critical temperature condition detected (XXX)*, hardware is being shut down”. *XXX is IPSOC or SFP
        Plura IP 2110 Monitor Temperature
        Temperature Warning On Display
        The new Web UI 3.0.0 will include the below new addendums and enhancements.
        • Animated and descriptive Web UI home page with two control partitions / Sections.
          • Monitor Control & Update section
          • Media LAN 2110 Control section
          Plura IP 2110 Monitor Web UI 3.0.0
          Web UI 3.0.0 Home Page
          • Monitor Control & Update section will provide
            • Monitor controls such as Power ON / Power OFF operation
          Plura IP 2110 Monitor control web page
          Monitor Control Web UI Page
          • To update any current and add any future licenses with status detection such as
            • 2110 / 2022-7
            • Ember+
            • TSL
            • JPEG-XS* future Planning
          • To update License (Ember+, TSL, 2110 SC) as shown below
          Plura IP 2110 Monitor license update
          License Update Page
          • To update Web UI latest version as shown below
          Plura IP 2110 Monitor web ui update
          Web UI Update Page
          • Media LAN Control 2110 (Out-Band) section will provide
            • Main stream configurations “The main stream which will be displayed on the Plura IP 2110 monitor”. Refer to the SFP-25G and SFP-25G-H production workflow article link here.
            • Main Stream 2022-7 Hitless switching ON / OFF toggle
            • Main Stream primary and secondary signal configurations, RX Packets and status
            • Importing SDP Files
          Plura IP 2110 Monitor main stream config
          Main Stream Configuration Page

          Plura IP 2110 Monitor SDP config
          SDP Import Page
          • Aux stream configurations. “The auxiliary stream De-Encap is outputted as SDI signal from the Plura IP 2110 monitor”. Refer to the SFP-25G and SFP-25G-H production workflow article link here.
            • 2022-7 Hitless switching ON / OFF toggle
            • Aux Stream primary and secondary signal configurations, RX Packets and status
            • Importing SDP Files, Same process shown above can be repeated for importing SDP for Aux Stream
          Plura IP 2110 Monitor Aux stream config
          Aux Stream Configuration Page
          • PTP Configurations and Status
            • Lock Status
            • Master ID
            • Master Version
            • Offset in Micro seconds
            • Active source 1 & 2 information along with Domain number and VLAN ID
          Plura IP 2110 Monitor PTP config
          PTP Configuration Page
          • Management IP configurations and Status
            • Primary IN-Band Media LAN IP address
            • Secondary IN-Band Media LAN IP address
            • Primary and Secondary Transceiver Information
          Plura IP 2110 Monitor management config
          Management Configuration Page
          Plura IP 2110 Monitor SFP primary
          Primary SFP Transceiver Information

          Plura IP 2110 Monitor sfp secondary
          Secondary SFP Transceiver Information
          • REST API Client
            • Additional configurations and status are currently available via in-band REST API
            • Management interface support (NMOS In-band)
              • NMOS (Out-band) through control lan2 is on the roadmap
              • NMOS is always enabled. The input stream selection occurs through network discovery and communication with facility automation.
              • NMOS uses the address of the unit’s in-band network interface for communications. When the monitor boots up, it actively scans the network for an NMOS registry using MDNS/DNS. If it finds one, it will provide the NMOS registry its ID and its capabilities
              • If the Monitor does not find an NMOS registry, it continues to announce itself through MDNS so that it can be discovered. Once discovered, it registers itself with whatever has discovered the unit through MDNS.
            • IP 2110 Video Format Frame Rate Support
              • The IP 2110 module supports the use of one frame rate type for both the Main and Aux channels’ video format settings
              • The frame rate type can be either integer, for video formats such as 1080p50, or fractional, for video formats such as 1080p59.94
              • In the event Main and Aux are set to different video formats frame rates, loss of signal to one channel will be observed. i.e., the last channel (Main/Aux) that is set will control the video format frame rate being applied. Thus, when a channel’s video format is set with a frame rate that does not match the other channel’s video format, the newly configured channel’s signal will work while the other channel’s signal will be lost
              • You will see a warning about the frame rate configuration when hovering over the video format field in the web UI
            Plura IP 2110 Monitor input format
            Frame Rate Configuration Warning
            • Ember+ and Plura IP 2110 monitor System Log Access
              • The Ember+ and IP 2110 system logs can be accessed via the Web UI by appending ‘/logs’ to the Control LAN 2 IP address in your browser address bar.
              • For example, if your Control LAN 2 IP address is 10.0.1.209, you can access the web UI logs here: 10.0.1.209/logs
              • To return to the normal web UI control and configuration, use your browser’s back button
            Plura IP 2110 Monitor system log
            Ember+ IP 2110 System Log

            SFP-25G, SFP-25G-H and SFP-10G Interoperability
            Plura IP 2110 Monitor interoperability

            Ember+, NMOS, JT-NM Interoperability Support

            • Management Interface support (NMOS, In-band) and (Web UI / Ember+, via the Out-band control network port)
            • NMOS IS-04 discovery and registration
            • NMOS IS-05 device connection management
            • JTNM NMOS certification support
            • JSON snippet for NMOS control support
            • Ember+ support with extensive Ember+ tree control
            • Session Description Path “SDP” file support
            • IGMP V2 & V3 support
            • Plura IP 2110 web user interface “UI” support

            ST 2110, ST 2022-7 & PTP/ST 2059 V2

            • ST 2059-1/-2 provisions, Signal will be locked to PTP and aligned to ST 2059 provisions
            • ST 2110-10, System architecture and synchronization: essences, RTP, SIP and PTP
            • ST 2110-20, Uncompressed video transport, Wide / Narrow types
            • ST 2110-21, Traffic shaping and network delivery timing
            • ST 2110-30, Audio transport profile level C, 16CH, 48Khz sample rate, 11ms/.125μs
            • ST 2110-40, Transport of ancillary data
            • ST 2022-7 seamless protection switching providing data loss protection
            To lean more about SFP-25G
            To lean more about SFP-25G-H
            To lean more about SFP-10G
            more in depth technical discussion
            Posted on by

            NEW Web UI 3.0.0 Release

            SFP-25G / SFP-25G-H / SFP-10G Series

            “TRUE-IP 25GbE / 10GbE 2110 4K/UHD and 3G/FHD Series”

            Our engineering team been working hard to bring you our next-generation software release. The new SFP-25G, SFP-25G-H and SFP-10G firmware (V22.12.0XX) and associated web UI (3.00) launch are just around the corner Dec 15, 2022, delivering fresh new enhancements that provide automatic IP stream measurements, values and SFP fiber data from the dual SFP28 / SFP+ sources directly on your monitor. We’re also bringing new monitor options, short and long terms licensing modes, and many more!

            PTP UI Configuration
            • More compact, highly efficient and comprehensive monitor connectivity.
            • Incremental and differential data analysis.
            • OSD informative messaging and alarms.
            • New and incredibly vast configuration UI and display options.
            Media Lan On display Information

            As the new modern IP workflow undergoes a major digital transformation, so too is our monitoring solutions evolving to better display your critical data. Don’t miss out on this important release.

            Main Stream UI Configuration

            “Register now to schedule time to demo the New Release and learn more about how to take advantage of all the new features.

            Click here to register
            Interoperability
            SFP-25G, SFP-25G-H and SFP-10G Interoperability

            Ember+, NMOS, JT-NM Interoperability Support

            • Management Interface support (NMOS, In-band) and (Web UI / Ember+, via the Out-band control network port)
            • NMOS IS-04 discovery and registration
            • NMOS IS-05 device connection management
            • JTNM NMOS certification support
            • JSON snippet for NMOS control support
            • Ember+ support with extensive Ember+ tree control
            • Session Description Path “SDP” file support
            • IGMP V2 & V3 support
            • Plura web user interface “UI” support

            ST 2110, ST 2022-7 & PTP/ST 2059 V2

            • ST 2059-1/-2 provisions, Signal will be locked to PTP and aligned to ST 2059 provisions
            • ST 2110-10, System architecture and synchronization: essences, RTP, SIP and PTP
            • ST 2110-20, Uncompressed video transport, Wide / Narrow types
            • ST 2110-21, Traffic shaping and network delivery timing
            • ST 2110-30, Audio transport profile level C, 16CH, 48Khz sample rate, 11ms/.125μs
            • ST 2110-40, Transport of ancillary data
            • ST 2022-7 seamless protection switching providing data loss protection
            To lean more about SFP-25G
            To lean more about SFP-25G-H
            To lean more about SFP-10G
            more in depth technical discussion
            Posted on by

            SFP-25G and SFP-25G-H Series from Plura supporting ST-2110 production workflow

            The SFP-25G and SFP-25G-H provides comprehensive interoperability capabilities with wide range of third-party IP-UHD-FHD media platforms with a seamless end-to-end production workflow. It can decodes multiple SMPTE 2110 & 2022-7 media streams within any broadcast and professional media SDI & IP 2110 infrastructures.

            SFP-25G production workflow
            SFP-25G and SFP-25G-H Production Workflow

            SFP-25G and SFP-25G-H from PLURA are the industry’s first TRUE-IP 25GbE broadcast & media monitor solution, supporting uncompressed UHD based on SMPTE ST 2110 & ST 2022-7. The flexibility and robustness of the SFP-25G and SFP-25G-H platforms are the ultimate solution for wide range of broadcast and professional media SDI to IP transition projects. The SFP-25G and SFP-25G-H platforms are powerful hybrid solution supporting SFP+ / SFP28 10G / 25G (ST 2110,ST 2022-7), 12G, 3G & 1.5G connectivity. The SFP-25G and SFP-25G-H provide comprehensive interoperability capabilities with major and wide range of prominent third-party IP-UHD-FHD ready media solutions, providing our customers the ease of mind and adaptability to utilize Plura IP solutions with a variety of technology suppliers for a seamless end-to-end production workflow. The SFP-25G and SFP-25G-H series features 2x 10/25 GbE SFP+/SFP28 complying with SMPTE ST 2022-7, seamless protection switching providing data loss and redundancy protection for critical distribution and monitoring applications “hitless switching”. The SFP-25G and SFP-25G-H monitor series are available in multiple sizes starting from 9″ all the way to 86″.

            Interoperability
            SFP-25G and SFP-25G-H Interoperability

            Ember+, NMOS, JT-NM Interoperability Support

            • Management Interface support (NMOS, In-band) and (Web UI / Ember+, via the Out-band control network port)
            • NMOS IS-04 discovery and registration
            • NMOS IS-05 device connection management
            • JTNM NMOS certification support
            • JSON snippet for NMOS control support
            • Ember+ support with extensive Ember+ tree control
            • Session Description Path “SDP” file support
            • IGMP V2 & V3 support
            • Plura web user interface “UI” support

            ST 2110, ST 2022-7 & PTP/ST 2059 V2

            • ST 2059-1/-2 provisions, Signal will be locked to PTP and aligned to ST 2059 provisions
            • ST 2110-10, System architecture and synchronization: essences, RTP, SIP and PTP
            • ST 2110-20, Uncompressed video transport, Wide / Narrow types
            • ST 2110-21, Traffic shaping and network delivery timing
            • ST 2110-30, Audio transport profile level C, 16CH, 48Khz sample rate, 11ms/.125μs
            • ST 2110-40, Transport of ancillary data
            • ST 2022-7 seamless protection switching providing data loss protection
            To lean more about SFP-25G
            To lean more about SFP-25G-H
            more in depth technical discussion
            Posted on by

            Plura Celebrates 15 Years

            We thank you for your trust in us and for being an essential part of Plura’s success.

            Plura’s 15th Anniversary Video

            Our CEO Ray Kalo, ponders on our distinguished journey and looking forward to the future:

            Year 2021 marks a very special year for Plura as we celebrate our 15th anniversary. Plura was founded in 2006. We went from an engineering conceptual idea for enriching the video monitor essence in the broadcast market, manufacturing and producing reliable, cost effective and rich feature solutions to a recognized and reputable technology solution provider in a global marketplace.

            Embracing Yesterday

            There are many positives & negatives to be learned from the past and I think it constitutes to two simple elements. Firstly, NOTHING is Impossible! Even though at the onset of this voyage our plans, goals, and objectives were simply idealistic and debatable. Nevertheless, we were committed to tackle these challenges head-on. We worked tirelessly to achieve these goals and deliverables, learn from our mistakes and never give up. Secondly, Express Respect and Integrity which are not only important for our company philosophy, but crucial to assembling an international company that is able to develop business relationships in a worldwide economy.

            Our drive is based on being unconventional and taking risks. We love to go against the odds, even in competitive and challenging markets.

            Through organic growth and acquisitions we strengthened our business; building a customer base that is unique in our industry. Plura has and continues to become the trailblazer in providing integrated monitoring solutions with SFP “Small Factor Pluggable” in IP 2110 & Coaxial globally. In addition we’ve reached a unique scale and level of expertise in timing solutions that meets our customers’ critical precision and synchronization timing needs.

            The People Factor

            Without the people help, this journey wouldn’t be possible….

            Firstly, big thank you to our trusted patrons for believing in us for many years and making us a prominent supplier in our industry. We are privileged to have your trust and will work vigorously to continue to earn it.

            Secondly, I am appreciative to our dedicated employees for the opportunity to work with amazing, enthusiastic and gifted people. Your pledge to serve our customers with respect and integrity that coincide with our corporate values have been vital to Plura’s progress and evolution.

            Last but not least, we acknowledge the significance of ascertaining joint alliances with our business partners that create exceptional attributes to both Plura and our customers. We thank you for your endurance, dedication and know-how skills to be part of serving thousands of customers all around the world.

            Planning for the Future

            It comes with no surprise; the past year has been very challenging in the global economy.  Plura is committed – and prepared – to serve our industry while also keeping our employees safe. Our intuitive developments and innovations haven’t changed and is still moving FORWARD.

            This year 2021, Plura is investing extensively in new technology initiatives. We are committed to be ready for the new wave of business opportunities as the prominent IP 2110 technology solution provider, offering our fully managed solution, Plura PTP, 10G & 25G, in an integrated platform. We continue planning for new products, streamlining our global operations, enhancing customer experience and continuing to deliver cost effective and future proof solutions to our customers.

            Our Pledge

            This mission has been anything but easy…. We will keep our foot on the accelerator and the accelerator on the floor. We continue to be fearless, passionate, distinctive and dedicated. As Plura celebrates its 15th anniversary, we salute each and every one -customers, employees and partners- whom has been an essential part of Plura’s success and helped shape our future.

            We look forward to continuing this journey together….

            Posted on by

            Plura extends Ember+ & TSL support simultaneously to various monitors.

            Ember+ & TSL capabilities support with ember+ H/W option is NOW available to many Plura monitor series such as PBM-4K, PBM-4K-H, SFP-H-7, SFP-H, PRM-3G, PBM-3G and LCM-3G.

            Plura Broadcast, a global manufacturer of high-performance digital broadcast and video production solutions, Plura unveils the availability of Ember+ & TSL protocol control with the majority of the Plura monitor series.

            Many Plura monitor series offer Ember+ compliant control system capabilities, i.e. can be controlled by Lawo-VSM, BFE-Core or any other Ember+ compliant control system.

            The ember+ capability is standard in PBM-4K and PBM-4K-H and is available as an option in the SFP-H, SFP-H-7, PRM-3G, PBM-3G & LCM-3G series. The innovation of this product is a combination of multi-Core powerful H/W and S/W platforms to adapt and process multiple protocols.

            As an extension to the successful ember+ capabilities, we have added TSL support using the same CONTROL LAN PORT.  The same CONTROL LAN PORT can be also be utilized for F/W & FPGA update along with web URL control and product information.

            The core of this platform is based on fully programmable architecture. Future proof expansion (i.e. additional features and functionalities can and will be implemented in the field via the CONTROL LAN PORT.

            To Learn more about how Ember+ can be added to your existing Plura monitor contact our team

            ABOUT Plura Broadcast

            Plura is a leading global manufacturer of a wide range of high-performance multi-function monitors (up to 84″) including 4K and Timing/Synchronization solutions engineered for digital broadcast and professional video production. Plura products offer an incomparable feature set, superior picture quality and extraordinary value and reliability. Plura is known for truly affordable high-end features built upon core technology.  The company’s solutions include studio and portable video monitors, studio production timer, Time-code displays & Time-code PCIecards, test and measurement equipment and software, character/template-driven graphics generators, and digital signage systems.

            Posted on by

            Withdrawal from IBC 2020

            Phoenix, AZ. – May 1, 2020 – Plura Broadcast, Inc and Plura Europe GmbH would like to announce that we have officially withdrawn and cancelled our IBC 2020 exhibition participation in Amsterdam, which is currently scheduled for Sept. 11-14.

            The current pandemic is the key factor in this decision. COVID-19 has already caused the cancellation of many other shows such as 2020 NAB Show and the postponement of others such as Broadcast Asia 2020 & Cabsat 2020.

            So you can imagine it has been a very difficult decision to make with many deliberations with our staff and our acquaintances. said Ray Kalo, President & CEO of Plura.

            “Since its inception in 2006, Plura has been committed to our industry tradeshows and participated in IBC every year. We take these trade shows seriously and prepare for them all year round. These trade shows keep our engine running with innovation, aspiration and motivation. It came down to what matters most….Bottom line …We value the well being of our employees and their loved ones.”

            Our emphasis now is bridging the current social gap with our customers during these challenging times and how to keep them fully updated and supported with the latest solutions and innovations from Plura.

            Plura is starting to adapt to the new reality, it’s time to brainstorm for new ways to communicate with our customers bearing in mind the health factors and social distancing methodology. This is NOT going to be easy, our industry is formed around face-to-face interaction, and it might continue to be so but in a different form. “time will tell”.

            In the next few days Plura will invite our customers to schedule a one on one online appointment in addition we will implement virtual individual and group meetings to stay connected with customers and partners.

            Plura is committed – and prepared – to serve you while also keeping our employees safe. Our entire team would like to thank you your the trust and support in us. We’re on this journey with you and look forward to supporting you in whatever way we can.

            Be well, safe and stay healthy……

            To Learn more about this article contact our team

            ABOUT Plura Broadcast

            Plura is a leading global manufacturer of a wide range of high-performance multi-function monitors (up to 84″) including 4K and Timing/Synchronization solutions engineered for digital broadcast and professional video production. Plura products offer an incomparable feature set, superior picture quality and extraordinary value and reliability. Plura is known for truly affordable high-end features built upon core technology.  The company’s solutions include studio and portable video monitors, studio production timer, Time-code displays & Time-code PCIecards, test and measurement equipment and software, character/template-driven graphics generators, and digital signage systems.

            Posted on by

            PBM-224-4K-DUAL

            Phoenix, AZ. – Feb 20, 2020 – Great engineering idea from a devoted PLURA user was developed and executed as PBM-224-4K-Dual. It is a customized system that is designed specifically to retrofit current HD/SD OB trucks with UHD system. Replacing aging HD/SD monitors with the new PBM-224-4K-Dual which is a great space management solution for the entire video wall. It is also ideal solution for many video & computer workstation applications such as video editing systems or alike.

            Product Highlights

            The NEW PBM-224-4K-DUAL, Dual 24″ monitor supports up to 4096 x 2160 resolutions, focuses on delivering the highly detailed, accurate color representation and stunning picture consistency that high-end production applications require.

            PBM-224-4K-DUAL Product Page

            The PBM-224-4K-DUAL monitor supports ST-2082, ST-2110, ST-2022 and other earlier industry standards, 4 x 12G/3G/HD/SD-SDI inputs with active loop, 4 x SFP+ inputs & HDMI 2.0.

            The PBM-4K series offers HDR Display capabilities supporting PQ (ST-2084) & HGL standards. The PBM-4K series also adopts the exceptionally slim form factor that Plura customers enjoy, ensuring that even the largest 4K monitors in the portfolio demand a modest slice of real estate

            Ember+ Support

            The NEW PBM-224-4K-DUAL can be controlled by Lawo-VSM, BFE-Core or any other Ember+ compliant control system.

            “Combining our creative and technical resources contributed to the successful launch of many products such this one and we’re looking forward to extending Plura’s creative product offerings across many more applications and projects. We’d love to hear what kind of creative and/or technical challenges you may be facing, and how we can aid you in achieving something amazing”.

            To Learn more about PBM-4K or PBM-224-4K-DUAL contact our team

            ABOUT Plura Broadcast

            Plura is a leading global manufacturer of a wide range of high-performance multi-function monitors (up to 84″) including 4K and Timing/Synchronization solutions engineered for digital broadcast and professional video production. Plura products offer an incomparable feature set, superior picture quality and extraordinary value and reliability. Plura is known for truly affordable high-end features built upon core technology.  The company’s solutions include studio and portable video monitors, studio production timer, Time-code displays & Time-code PCIecards, test and measurement equipment and software, character/template-driven graphics generators, and digital signage systems.

            Posted on by

            I.M.D.P. CONTENT CREATION + AESTHETIC DISPLAY

            Phoenix, AZ. – Dec. 10, 2019 –With decades of experience collaborating with brands, agencies and content creators around the globe, Nice Shoes and Plura have partnered to offer state of the art I.M.D.P. (Intelligent Media Display Platform) media solution which is driven by Media Creation and Aesthetic Display Technology.

            Bringing together ideation and eye-popping visuals with high quality custom-tailored color matching displays and play out server solutions, this partnership has developed a system that can be bespoke to any scale you can imagine.

            What is I.M.D.P.

            The NEW and state of the art I.M.D.P. Intelligent Media Display Platform solution is one of it’s a kind system experience and based on specific project elements. In a nutshell the I.M.D.P system consists of high level project components and milestones starting from ideation, media creation, high quality custom-tailored color matching displays and play out server. All these elements combined will be tailored to every project in a different way. The I.M.D.P. system can be customized to any scale you can imagine.

            I.M.D.P. Product Page

            Ingenuity and Imagination are ENDLESS with I.M.D.P.

            The National Museum of Qatar / Alchemy Gallery 10 project

            “Combining our creative and technical resources contributed to the successful launch of the museum, and we’re looking forward to extending Nice Shoes and  Plura’s creative partnership across many more projects. We’d love to hear what kind of creative or technical challenges you may be facing, and how we can aid you in achieving something amazing”.

            HOW CAN WE HELP?

            Contact:

            Ray Kalo
            PLURA
            rkalo @ plurainc.com

            or

            Mike Palmer
            NiceShoes
            mpalmer @ niceshoes.com

            Posted on by

            Plura extended its IP support with SFP-H-7 series and SMPTE ST-2022-7 at 2019 IBC Show.

            SFP-H-7 monitor series provides innovation and flexibility for broadcasters, sports and other advanced production applications – with ST-2022-7 compliance.

            Plura Broadcast, a global manufacturer of high-performance digital broadcast and video production solutions, Plura unveils the NEW SFP-H-7, Hybrid Monitor Series, supporting Coax, and Fiber & IP at the 2019 IBC Show.

            The Plura SFP-H-7 is derivative of the popular SFP-H Hybrid Monitor Series, supporting Coax, Fiber & IP connectivity.  In addition the SFP-H-7 series complies with SMPTE ST 2022-7 and Ember+.

            The SFP-H-7 series comes standard with PIPM-R-7. “Plura FPGA based module which supports 3G SMPTE ST 2110 signals across 10 GigE and it features 2x 10 GbE SFP+ cages complying with SMPTE ST 2022-7, providing redundancy protection for critical distribution and monitoring applications “hitless switching”.

            SFP-H-7 monitor series supports Ember+ control system protocol. All SFP-H-7 monitors can be controlled by Lawo-VSM, BFE-Core or any other Ember+ compliant control system.

            The SFP-H-7 monitor series will be available in multiple sizes starting from 17″ all the way to 84″.

            The SFP-H is integrated with powerful H/W & S/W platforms to support Coaxial 3Gb/s BNC I/O connectivity, Coaxial SFP I/O connectivity, IP SFP+ over Fiber  De-Encap “ST-2110 & ST-2022” with Third-Party H/W.

            The main objectives of this product is to process, monitor and analyze multi-Format signals including IP streams directly on the monitor without using external hardware such as converters or Gateway to convert different type of signals into a base-band coaxial HD signal before the monitor.

            The innovation of this product is a combination of multi-Core powerful H/W and S/W platforms to adapt and process multiple protocols.

            “As an extension to the successful SFP-H Hybrid series, Plura is glad to introduce the new and distinctive SFP-H-7 IP monitor with ST-2022-7 and Ember+ support, many customers have requested such technology to be embedded within our monitors and we have delivered their wishes.” said Ray Kalo, president, Plura.  “Plura is committed to the IP 2110 & 2022 long term initiative and planning. We will not stop here and will continue to evolve our solutions to suit any studio or mobile IP and/or Coaxial production workflow, and equally keeping the affordability factor in our agenda”.

            Plura Broadcast will have multiple SFP-H-7 units display including the new PIPM and Smart Service Telemetry Platform at the 2019 IBC Show, Hall 8 Stand 8B73.

            To learn more about SFP-H-7 series …click here

            ABOUT Plura Broadcast

            Plura is a leading global manufacturer of a wide range of high-performance multi-function monitors (up to 84″) including 4K and Timing/Synchronization solutions engineered for digital broadcast and professional video production. Plura products offer an incomparable feature set, superior picture quality and extraordinary value and reliability. Plura is known for truly affordable high-end features built upon core technology.  The company’s solutions include studio and portable video monitors, studio production timer, Time-code displays & Time-code PCIecards, test and measurement equipment and software, character/template-driven graphics generators, and digital signage systems.
